Quicksilver 88688A23 User Manual

Template for Dual and Single
Console Controls
Centerline for
1/4” (.25” or 6.35mm) Dia. for Single Control
Centerline for Dual Control
Outline of Remote Control Cover for
Dual Control
a-
l
3/8” (9.53mm) Dia. for Single Control
I
I
I
Outline of Remote Control Cover for Single Control
iJ
I
I
. . -
-
t
ACAUTION
Area (located directly under mounting panel) must be free from obstructions
and must allow cables to form a gradual bend when routed toward stern of
boat.
-15-
