Quicksilver 905WE — System & Component Overview and Operaon
24
Pump to head sink tube
Boiler to head sink tube
Head sink faucet
Pump to transom shower tube
Boiler to transom shower tube
Transom shower
City water inlet
Fresh Water System - Hot and Cold
Water tank ll
Water tank ll hose
Water tank vent
Water tank vent hose
Water tank
Tank to pump hose
Water pump
Water pump lter
Water pump to boiler tube
Boiler
Pump to galley sink tube
Boiler to galley sink tube
Galley sink faucet
Make sure that the fresh water tank is full before operang
the boiler. Operang the boiler empty will cause damage to
the system.
SCALDING INJURY — Turn o the boiler and wait for the
water in the tank to cool down before operang the relief
valve to ush the tank.
3. Black Water System
Your vessel is equipped with a waste containment / disposal system. This includes a toilet water
pickup, an electric ush toilet, a 100 liter holding tank, macerator, discharge seacock, and a dockside
pump out connecon.
Operaon
Prior to using the toilet, make sure that the toilet water pickup valve, located under the interior oor
liner access cover, is opened. To operate, simply press and hold the switch located on the head sink
basin unl the bowl is thoroughly rinsed and there is no water at the base of the bowl. Refer to the
toilet owner's manual in regards to specic operaon of the toilet.
