Quicksilver 675OP — System & Component Overview and Operaon
22
Steering wheel
Hydraulic uid ll
Helm pump
Steering hose
Steering cylinder
Hydraulic Steering
8. Engine Controls
Depending on the engine installed on your boat, you will either have a mechanical gear shi/throle
control unit or a “drive by wire” Digital Throle and Shi (DTS®) control unit. The control unit, located
to the starboard of the steering wheel, acvates both the shiing and throle for the engine.
To start the engine, the control unit must be in the NEUTRAL posion. When in neutral, the engine is
running, but the propeller is not spinning. There is a “Throle-Only” buon that when pressed, will
allow you to operate the throle without the propeller spinning. On the mechanical shi controller,
the buon is located at the center of the throle control, and when moved back to the center
posion, the buon will automacally re-engage the shiing mechanism.
For the DTS control, the “Throle-Only” buon is located on the control funcon pad. To engage,
press the “Throle-Only” buon on the keypad when the engine is in neutral. A light located above
the “Throle-Only” buon will turn on and the green neutral light will begin to ash. When you place
the ERC in gear, the warning horn will beep, however, the propeller is not turning. To disengage,
return the ERC lever back to neutral and press the “Throle-Only” buon. The light located above the
“Throle-Only” buon will turn o and the green neutral light stops ashing and remains illuminated.
Moving the control lever forward from neutral engages the forward gear and throle advance.
Moving the control lever backwards from neutral engages the reverse gear and thrust. The throle
lever controls the RPM of the engine and the speed of the boat.
Power Trim & Tilt
The power trim, located on the side of the gear shi throle handle, allows you to raise and lower the
engine for trailering and launching the boat. It also allows you to adjust the engine to create the
opmum run angle for the boat to achieve best all around performance (fuel consumpon, speed).
REFER TO THE ENGINE MANUFACTURER’S MANUAL FOR COMPLETE INSTRUCTIONS, INFORMATION
AND WARRANTY.
