Operating Procedures / Photos
Evaporator
clasp
screw
screw
Evaporator
Disassemble Motor
Use screwdriver to unscrew the two screws fixing
the motor clamp, and remove the motor clamp.
Unscrew the three holding screws at the shaft
sleeve, and remove the motor.
motor clamp
Screw
screw
Motor
Axial fan
