9- TYPICAL INSTALLATION
FIG. 9
CONNECTIONS CABLES
Cables section sqmm
1 POWER SUPPLY 3x1,5
2 TX PHOTOCELL ON POST 2x0,75
3 RX PHOTOCELL ON POST 4x0,75
4 TX PHOTOCELLS 2x0,75
6 RX PHOTOCELLS 4x0,75
5 KEY SELECTOR 3x1
7 FLASHING LAMP 2x1
8 AERIAL RG59
FOR THE ELECTRICAL CONNECTIONS REFER TO THE USER MANUAL OF THE CONTROL BOARD
