Section II - Description
6 Quincy Compressor
1 Electroniccontroller S3 Emergencystopbutton
2 Hour meter
QOF 30 with dryer, rear view
1 Compressor module 3 Refrigerant dryer
2
Aircooler 4 Compressed air outlet valve
Compressor element operating principle
Eachcompressorelementconsistsofaxedscrollshapedhousingandascrollshaped
rotor.Airentersthecompressorelementthroughinletopening(1).Oncetheairisdrawn
in,theorbitingscroll(4)sealstheinletopeningandforcestheairintoacontinuously
decreasingspace.Asscroll(4)keepsorbiting,thisprocessofcompressionisconstantly
repeated,resultingindischargingofoilfreecompressedairthroughoutletopening(3).
