Section III - Airlogic Graphic Controller
Calling up menus
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Description
When the voltage is switched on, the main screen is shown automatically.
• To go to the Menu screen, select Menu, using the Scroll keys
• Press the Enter key to select the menu. Following screen appears:
Quincy Vacuum Pump-QSV Series 25
