QR 325 Quincy Compressor
50215-106, January 2014 4 3501 Wismann Lane, Quincy IL - 62305-3116
CRANKSHAFT GROUP 110238
Item Part
Number Qty. Number Description
1 1 110217 crankshaft assembly
1.1 1 110216 crankshaft (N.S.S.; order 110217)
1.2 1 110234 orifice, 1/8 npt
1.3 2 2755S pipe plug, 1/8 npt
1.4 1 2585 bearing cone
1.5 1 2788 bearing cone
1.6 1 110705-F15 pin
2 1 1466 key
3 1 110472X sheave assembly
3.1 1 4126R sheave, 16", 2 groove, B sect., ccw (N.S.S.; order 110472X)
3.2 2 110983-N23 hex. screw, 1/2-13 unc x 3.50, grade 8 (@ 90 ft.-lbs.)
3.3 2 116124-N02 square nut, 1/2-13 unc
3.4 2 110428N050 flatwasher
N.S.S. = Not Sold Separate
@ Indicates torque value in foot pounds (dry threads)
Note: For reversal of compressor rotation refer to QR-25 instruction manual.
