Quincy 325 - BEARING CARRIER GROUP 110816-001 (with oil filter); Bearing Carrier Assembly Components; Maintenance Parts for Oil Filter Kit

QR 325 Quincy Compressor
50215-106, January 2014 8 3501 Wismann Lane, Quincy IL - 62305-3116
Item Part
Number Qty. Number Description
BEARING CARRIER GROUP 110816-001
(with oil filter)
*
*
*
*
1 1 110810-003 bearing carrier assembly (N.S.S.; order 110810X003)
1.1 1 110810 bearing carrier (N.S.S.; order 110810X003)
1 2523 bearing cup
2 160005 bushing
1.2 1 123157-152 "o"ring, 3/32 wide x 3.44 o.d.
1.3 1 123157-112 "o"ring, 3/32 wide x .69 o.d.
1.4 1 160002-002 driveshaft
1.5 1 160075-001 driveshaft key
1.6 1 160003 pump gerotor
1.7 1 6285 retaining ring
1.8 1 110813-001 oil pump housing
1.9 6 123777-J12 hex. screw, 1/4-20 unc x 1.00, grade 5 (@ 6 ft.-lbs.)
1.10 2 2719 pipe plug, 1/4 npt, hex socket
1.11 1 5489 adjustment screw
1.12 1 123157-011 "o"ring, 1/16 wide x .44 o.d.
1.13 1 124369-P02 jamnut, 9/16-18 unf
1.14 1 1160 spring
1.15 1 112857 needle valve
1.16 2 6565 hole plug
1.17 1 2755S pipe plug, 1/8 npt
2 1 6312 gasket, bearing carrier
3 6 123478-L12 hex. screw, 3/8-16 unc x 1.00, grade 5 (@ 30 ft.-lbs.)
4 1 110822 oil pressure gauge
5 1 110825 stud
6 1 110814-001 6 pack of oil filters
160078 Oil Pump Repair Kit
includes "o"rings, driveshaft, key, pump gerotor, & retaining ring
110810X003 Replacement Bearing Carrier Assembly
includes bearing carrier assy., oil filter, stud, & bearing carrier gasket
Maintenance Parts
*
N.S.S. = Not Sold Separate
@ Indicates torque value (dry threads). Tighten multiple bolts, capscrews & hex nuts in a criss-cross or alternating pattern. Bring
each fastener to the recommended torque specification in even increments.
* Can not be used with diester or phosphate ester synthetic lubricants.
§ Install with Teflon
®
tape.
§
§
