Quooker CUBE - Page 33

33
5 Disconnect the CUBE
Remove the blue communication cable from the top of
the CUBE and remove the plug from the power socket.
Now remove the hoses. You remove a hose by pushing-in
the plastic ring whilst simultaneously pulling out the hose.
Transport the CUBE in protective packaging.
6 Disconnect the boiling water tank
Switch o the Quooker tank and remove the T-joint on top
of the Quooker tank using spanner sizes 12 and 14.
7 Connect the boiling water tank
Reconnect the boiling water hose to the Quooker tank (with
a bre washer in between) using spanner sizes 12 and 14.
Then switch the tank on by pressing the Q button on the
top of the tank.
5 6
7
OUT
CO2
IN
