QUORION QTouch 10 User Manual

7
The test menu:
 „ESC“ Button: cancel and return to main menu
 „Printer“ Button: print out a test character set and test string set
energy level: change the print intensity (black level)
 „Cutter“ Button: cutter test
 „Drawer“ Button: open the cash drawer
 „Sensors“ Button: shows and tests the sensors
 „TFT“ Button: tests the operator displays with RGB and black / white colors
 „LCD“ Button: test the customer display with letter and number sequences
contrast level: change the contrast of the display
 „COM Port“ Button: tests the functionality of the COM ports
 „Protocol“ Button: create a test protocol (for production only)
QTOUCH 10 Test Hardware
Press ESC to Abort
Drawer
Sensors
Cutter
COM -
Port
LCD
TFT
Open Drawer
Get input from sensors
Test the operator display
Test for customer display
Test Com Ports with loopback
Cut paper
ESC
Printer
-
S
C
+
-
S
C
+
Print character font
Energy level: X
Contrast level: XX
Protocol
Production test with protocol
