Test modes during immunity tests:
1. Battery mode, standby armed/ready.
2. Charging mode, actuator not running.
EM immunity standards IEC 60601-1-2:2014 test levels Additional test levels
Electrostatic discharge
IEC61000-4-2
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ± 15
kV air
± 6 kV contact
Radiated RF EM elds
IEC 61000-4-3
3V/m (Professional)
10 V/m (Homecare)
80 MHz – 2.7 GHz
80 % AM at 1 kHz
20 V/m
800 MHz – 2.5 GHz
80 % AM at 1 kHz
Proximity elds form RF
wireless communication
equipment
IEC 61000-4-3
IEC 60601-1-2:2014 Table 9 N/A
Electrical fast transients /
bursts
IEC 61000-4-4
± 1 kV, ± 2 kV
5 kHz repetition frequency
N/A
Surges, Line-to-line
IEC 61000-4-5
± 0,5 kV, ± 1 kV, ± 2 kV N/A
Conducted disturbance
induced by RF elds
IEC 61000-4-6
6 Vrms
0.15 MHz - 80 MHz 80% AM
at 1 kHZ
0.15 MHz - 80 MHz 80% AM
at 2 kHZ
N/A
Rated power frequency
magnetic elds
IEC 61000-4-8
30 A/m
50 Hz and 60Hz
N/A
Voltage dips, short
interruptions and voltage
variations
IEC 61000-4-11
0 % UT for 0,5 cycle at 0°,
45°, 90°, 135°, 180°, 225°,
270° and 315° phase angles
0 % UT for 0,5 cycle
0 % UT for 1 cycle
70 % UT for 25 cycles (50 Hz)
70 % UT for 30 cycles (60 Hz)
0 % UT for 250 cycles
40 % UT for 5 cycles
