Rabbit P455SM - BEFORE OPERATION; Battery Connection for (S) Specification

8
DESIGNATION OF PARTS
OPERATING SIDE BACK SIDE
RECOIL STARTER SIDE PUMP SIDE
BEFORE OPERATION
(1) Confirm that a complete set of the standard equipment and accessories in the package.
(2) For (S) Specification, it is necessary to connect the battery with the terminals. First, detach the cover on the operation
side, and connect the battery with (+) terminal and (-) terminal. Detach the liquid port plug nearest to the (+) terminal
of the battery, and mount the battery liquid level sensor.
Exhaust Manifold
C
y
linder Drain Cock
I
g
nition Plu
g
Cove
r
Vacuum Pump
Air Exhaust Pipe
Recoil Starte
r
Recoil Starter
Handle
Batter
y
Oil Tank
Search Light
Receptacle Cap
Main Switch
Compound Pressure
Gau
g
e
Fuel Tank Cap
Fuse Bo
x
Throttle
Suction Leve
r
Pressure Gau
g
e
Rabbit Monito
r
Muffler Drain Cock
Dischar
g
e Valve
Fuel Cock
Discharge Valve
Drain Cock
Muffler Air
Exhaust Port
Stop Valve Water
Drain Button
Dischar
g
e Valve Handle
