Sensor Wires (Optional)
You are able to connect up to two
rain or flow sensors to your
controller using the “S1,” “S2,” and
24VAC sensor power terminals.
For more information, visit
rachio.com/sensors.
Master Valve
Not all systems have a master
valve. Master valve wires are often
labeled “M,” “MV,” or “Pump.” If you
have a master valve, wire it into the
dark gray “M” terminal.
M
S1-2 24 VAC
Insert the power connector upward into the power jack
located at the bottom right of the wiring bay. Then, plug
the power adapter into the outlet.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rachio 3 and is the answer not in the manual?

Rachio 3 Specifications

General IconGeneral
Weight1.1 lbs
Warranty2-year limited warranty
Water Usage ReportsYes
Zones8 or 16 zones
Wi-Fi Connectivity2.4 GHz
Weather IntelligenceYes
Mobile AppiOS and Android
Voice ControlAmazon Alexa, Google Assistant
Power SourcePlug-in transformer
