Remote Supervisory Control Output
Verbatim Owner's Manual C-3
Unless ordered otherwise, type OAC5 is normally provided from the factory.
Connect 120 VAC power as shown on this same diagram. Route modular
“Cable A” through one of the entrance holes on the bottom of the Verbatim
Autodialer, and plug it into J301 (the right-hand jack on the VCP circuit card,
see diagram). The 8-output VRSC-8 option also includes a second modular
“Cable B”, connect this to the adjacent jack J302 on the VCP circuit card.
Avoid routing these cables alongside power wiring and route them so that the
front panel circuit board does not pinch them when the door is closed.
C.1.2 Optional Direct Connection Without Use of Output
Relay Enclosure
The outputs on the VCP circuit card are NPN transistor open collectors capable
of switching up to 12 volts DC at up to 500 ma, and thus these outputs may in
some cases be connected directly to logic inputs of logic controllers, etc,
although external pullup resistors may be required. Consult Raco for details.
The color codes for VRSC cables “A” and “B” are:
Cable Color Code
Cable A
Common Return Black
Output # 1 Red
Output # 2 Green
Output # 3 Yellow
Output # 4 Blue
Cable B
Output # 5 Red
Output # 6 Green
Output # 7 Blue
Output # 8 Yellow
C.1.3 Remote Supervisory Control Operation
u To check the on/off status of output # N, use program code
9 5 N ENTER
where N is a 2 DIGIT output number (e.g. 01 for output # 1).
u To turn output # N ON, use program code
9 5 N 1 ENTER
u To turn output # N OFF, use program code
9 5 N 0 ENTER
