Verbatim Autodialer Specifications
I-6 Verbatim Owner's Manual
the main circuit board shall not be an acceptable substitute. The installer shall
provide a good electrical ground connection point near the unit to maximize the
effectiveness of the surge protection.
I.17 Local Data Logging
The system shall include a parallel printer interface for local data logging. The
local printer will automatically print out, with date and time stamp, each activity
that occurs; alarms, acknowledgements, programming entries, inquiry calls,
etc.. For the purpose of easy program review the user shall be able to printout
on demand all user entered programming.
I.18 Public Address Broadcast
The standard dialer shall provide a mini phone jack for optional connection to a
local public address system. If connected to the PA system the dialer shall
broadcast all alarm messages over the PA system and the telephone simul-
taneously.
I.19 Integral Surge Protection
All power, phone line, dry contact, and analog signal inputs shall be protected
at the circuit board to IEEE Standard 587, category B (6,000 volts open circuit/
3,000 amps closed circuit). Gas tubes followed by solid state protectors shall be
integral to the circuit board for each such line. Protectors mounted external to
the main circuit board shall not be an acceptable substitute. The installer shall
provide a good electrical ground connection point near the unit to maximize the
effectiveness of the surge protection.
I.20 Warranty
The dialer shall be covered by a five (5) year warranty covering parts and labor
performed at the Factory.
I.21 Modular Upgrades
The system shall include expansion connectors to accommodate field upgrades
for additional internal dry contact inputs, remote supervisory control outputs,
and internal analog inputs, CDL, SCADA.
