Advanced Programming
Verbatim Owner's Manual
6-11
2 ZZ Record Channel ZZ Used for Closed Circuit message for channels
Normal Message programmed for NO ALARM (Status Only) or for
Run Time Meter operation. Also used for “units of
measure” portion of a message following preamble
and digit readings, for channels programmed for
Totalizer or Analog function.
3 ZZ Review Channel ZZ Use 3 00 to review Station ID message
Messages
6.2.3 Channel Programming (Configuring)
Also see Section 3.3, “Programming Input Channels.”
Code Function Description
500 Set Present Input Status Used at setup time as the most expedient way of
as Normal Condition for All programming the Normally Open/Normally Closed
Contact Input Channels configurations (“Alarm Criteria”) of contact input
channels. Special configurations such as Status
Only, Run Time Meter or Totalizer may then be
programmed for specific individual channels. This
code does not affect channels already programmed
for Status Only, Run Time Meter, or Pulse
Totalizer.
APPLIES ONLY TO CONTACT INPUTS.
500 0 Sets the Alarm Criteria Used at setup time as the most expedient way of
for all contact channels to programming all channels to the same alarm
DISABLED criteria.
APPLIES ONLY TO CONTACT INPUTS.
500 1 Sets the Alarm Criteria Same as above
for all contact channels to
NORMALLY CLOSED
500 2 Sets the Alarm Criteria Same as above
for all contact channels to
NORMALLY OPEN
500 3 Sets the Alarm Criteria Same as above
for all contact channels to
STATUS ONLY
5 ZZ Read Channel ZZ
Programming (“Alarm
Criteria”)
5 ZZ 0 Disables Channel from
Being Monitored and Reported
5 ZZ 1 Set Channel ZZ for An Open Circuit condition will cause an alarm.
Normally Closed Operation APPLIES ONLY TO CONTACT INPUTS.
5 ZZ 2 Set Channel ZZ for A Closed Circuit condition will cause an alarm.
Normally Open Operation APPLIES ONLY TO CONTACT INPUTS.
5 ZZ 3 Set Channel ZZ for
No Alarm (Status Only) APPLIES ONLY TO CONTACT INPUTS.
