LEGEND-FIGURE 1
HEAD ADAPTOR ASSEMBLY
ITEM PART NO. DESCRIPTION
1 106010-1, -2, -3 Head Adaptor
2 7000-03 Cartridge Bearing
3 S2-16 Ultra Precision Shaft
4 6050-49 Fan Blade
5 106013-1 Sensor Disc
6 106004-1 Photo Sensor PCB Assembly
7 1350-22 Screw, 4-40 x .25 Pan Head
8 1550-88 Washer, Fiber, #4
9 2201-11 O-Ring
12 2201-09 O-Ring
