Radial Engineering Catapult Series User Manual

Radial Engineering Ltd.
Catapult™ Audio Snake
True to the Music
®
1
CATAPULT FEATURES
1
3
4 5 6 7
2
1. INPUT: XLR-F inputs used to connect a mic, instrument or mixer to
pass the signal to the RX module.
2. THRU: XLR-M thru wired in parallel with the option of mic or line-
level transformer isolation.
3. HANDLE: Protective steel handle makes it easy to pick-up and drop
wherever needed.
4. LIFT: Lifts the Cat 5 cable ground path to help eliminate troublesome
ground loop noise.
5. IN/OUT: Standard Ethernet connection for shielded Cat 5 cable
depending on the model used to send/receive audio from Catapult
modules.
6. THRU: Parallel connection from XLR outputs used to feed additional
Catapult modules.
7. BUMPER: Used to protect the Ethernet connectors and ground lift
switch from damage.

Radial Engineering Catapult Series Specifications

General

Brand	Radial Engineering
Model	Catapult Series
Category	Cables and connectors
Language	English
