5
The selection and preparation of the pool site is your responsibility. The manufacturer can
only suggest the proper techniques, indicate the important considerations and emphasize the
precautions and cannot be held responsible for damages to your pool that may result from failure
to carefully follow all pool specifications.
All Radiant Pool components are engineered to provide a precise fit. It is very important to handle
all components with care. Prior to assembly, all pool components should be free of sand, mud, dirt
and debris of any kind.
IMPORTANT: DO NOT ALLOW SPLINES OR COMPRESSION SEAMS TO COME IN CONTACT WITH
SAND OR OTHER DEBRIS AS THIS WILL CAUSE DIFFICULTY IN INSTALLATION.
We recommend a small broom or shop-vac to maintain a clean track system throughout the
installation process. In addition we recommend a damp cloth be available in the event that any dirt
or debris finds its way to the component surfaces.
Component 16’ 18’ 21’ 24’ 27’ 30’ 33’
Panels 8 8 10 10 10 12 14
Anchor Plates 8 8 10 10 10 12 14
Coping 8 8 10 10 10 12 14
White Cap Screws 50 50 50 50 50 100 100
Coping Clips 8 8 10 10 10 12 14
Splines 16 16 20 20 20 24 28
Bolts (3/8”x 2 1/2”) 16 16 20 20 20 24 28
Skimmer w/Mounting Kit 1 1 1 1 1 1 1
Return Fitting 1 1 1 1 1 1 1
Vinyl Liner 1 1 1 1 1 1 1
IMPORTANT: BEFORE YOU BEGIN
POOL COMPONENTS CHECKLIST
IMPORTANT: A concrete collar is required for any pool that is
installed 26” or greater in the ground. See page 21 for details.
