3
REC Indicator
Lights during
recording;
blinks during
pausing.
USB
Connects to PC for data transfer using
the supplied USB cable.
DC 6V
Connect AC power adapter (supplied)
or DC 6V adapter (not included).
* (Earphone)
Insert earphones (not supplied) for private
listening. The speaker is deactivated.
AUX-IN
Connect an audio source using a patch
cord with a 1/8-inch (3.5 mm) plug
(neither included).
MIC
Connect a 1/8-inch (3.5mm) plug
microphone (not included). The built-
in microphone is deactivated.
TONE
Increases or decreases the
high-pitched tone when playing.
VOL
Adjusts the volume level when playing.
MIC
Place sound source
