3
B. FUNCTION AND LOCATION OF THE CONTROLS
1. “ON/OFF” Volume Control.
Your transceiver is off whenever the knob points to the ‘OFF’ position. Rotate this control clockwise to
turn on your radio and adjust the volume.
2. SQL Knob
Rotate the
VOL/SW Knob
to obtain the squelch sensitivity at threshold.
3. CH
/Key Tone Button
Press
CH
to select a channel upwardly. Press and hold
CH
continuously for more than 1.5sec to
enter into the scan upwardly mode. Press
CH
will change the scanning direction downwardly. During
the scanning, press any key will exit the scanning mode.
Key Tone
Press and hold
FUNC
key, then press
CH
key to activate or deactivate the Key Tone function. Icon “
” will be shown if activated.
4.
CH
/ Skip
Press
CH
to move one channel down. Press and hold
CH
for more than 1.5sec to enter into the
scan downwardly mode. Press
CH
will change the scanning direction upwardly. During the scanning,
press any key will exit the scanning mode.
To Next Page
