Radio Shack Digital Recorder User Manual

23
message number that you
want to play back appears.
2. Press
PLAY/STOP
to start
playback.
3. Press
VOLUME +
or
–
to
adjust the volume.
4. To temporarily stop
playback, press
PAUSE/
DISPLAY
. To resume
playback, press
PAUSE/
DISPLAY
again.
±
5. To stop playback, press
PLAY/STOP
.
4GUWOG"2NC[
When you press
PLAY/STOP
during playback, the recorder
remembers the position. When
you press
PLAY/STOP
again,
the recorder starts playing the
message from the point where
you stopped it. If you press any
button other than
PLAY/STOP
,
that memory is lost.
±
"016'5"
±
"
(continued)
• File locations
start with
7¶&&
7¶&&7¶&&
7¶&&
or
8¶&&
8¶&&8¶&&
8¶&&
as the
first location,
7¶&'
7¶&'7¶&'
7¶&'
or
8¶&'
8¶&'8¶&'
8¶&'
as
the second, and
continue in this
fashion
throughout the
folder.
• The recorder
automatically
turns off if it is
set to pause for
more than 30
minutes.

Radio Shack Digital Recorder Specifications

General

memory size	8 MB
recording time (SP)	133 minutes
recording time (MP)	177 minutes
recording time (LP)	290 minutes
recording system	Built-In Flash Memory
power supply	DC 3V, two AAA alkaline batteries
battery life in recording mode	About 16 hours
battery life in earphone play	About 16 hours
battery life in speaker play	About 10 hours
maximum number of recording messages	495 Messages
files x messages	5 Files × 99 Messages
maximum output power	60 mW, at 8 ohm, 10% THD
frequency bandwidth	500 Hz to 3000 Hz
input	Plug-in microphone (mini plug, mono)
output	Earphone (mini plug, mono) impedance is 32 ohm
speaker	Built-in 20 mm diameter
microphone	Built-in omni-directional elect condenser microphone (mono)
operating temperature	0°C to 40°C
accessory	Wrist Strap

Weight and Dimensions

dimensions	4.1 × 1 × 0.7 inches, 104 × 26 × 18 mm
weight (without batteries)	Approx. 34 g
