41
2.
Image Window Icon
– Starts the Image
Window program.
3.
Image Viewer Icon
–
Starts the Image
Viewer program.
4.
Folder Refresh Icon
– Updates the data to
the PC.
5.
Connection Indicator
– Indicates the
connection status between
the recorder and the PC.
6.
Refresh Icon
–
Refreshes the
connection between the
recorder and the PC.
7.
Upload Icon
–
Uploads selected files
from the recorder to the
PC.
8.
Download Icon
–
Downloads selected

Radio Shack Digital Recorder Specifications

General

memory size	8 MB
recording time (SP)	133 minutes
recording time (MP)	177 minutes
recording time (LP)	290 minutes
recording system	Built-In Flash Memory
power supply	DC 3V, two AAA alkaline batteries
battery life in recording mode	About 16 hours
battery life in earphone play	About 16 hours
battery life in speaker play	About 10 hours
maximum number of recording messages	495 Messages
files x messages	5 Files × 99 Messages
maximum output power	60 mW, at 8 ohm, 10% THD
frequency bandwidth	500 Hz to 3000 Hz
input	Plug-in microphone (mini plug, mono)
output	Earphone (mini plug, mono) impedance is 32 ohm
speaker	Built-in 20 mm diameter
microphone	Built-in omni-directional elect condenser microphone (mono)
operating temperature	0°C to 40°C
accessory	Wrist Strap

Weight and Dimensions

dimensions	4.1 × 1 × 0.7 inches, 104 × 26 × 18 mm
weight (without batteries)	Approx. 34 g
