Radio Shack Digital Recorder User Manual

43
4700+0)"284"
/#0#)'4
1. Double-click the
RadioShack DR-97
icon or
click
Start/Programs/
RadioShack/DR-97/PVR
Manager
. The PVR
Manager starts and the
main window automatically
appears.
2. To exit RadioShack PVR
Manager, click
File/Exit
.
±
7RNQCFKPI"(KNGU
1. To save uploaded files in
the PC, voice, picture, and
email folders are
automatically created
under
C:/RadioShack/DR-
97
when PVR Manager is
installed. Specify one of
the folders so the folder
opens. If you do not
specify a folder, files will be
uploaded to the
DR-97
folder.
±
"016'"
±
"
Once the recorder
and the PC are
connected with USB
connecting cable,
9edd[Yj
9edd[Yj9edd[Yj
9edd[Yj
appears. If
the connection did not
work or was
obstructed,
B?DAý;hheh
B?DAý;hhehB?DAý;hheh
B?DAý;hheh
appears. If this
happens, click the
Refresh icon.

Radio Shack Digital Recorder Specifications

General

memory size	8 MB
recording time (SP)	133 minutes
recording time (MP)	177 minutes
recording time (LP)	290 minutes
recording system	Built-In Flash Memory
power supply	DC 3V, two AAA alkaline batteries
battery life in recording mode	About 16 hours
battery life in earphone play	About 16 hours
battery life in speaker play	About 10 hours
maximum number of recording messages	495 Messages
files x messages	5 Files × 99 Messages
maximum output power	60 mW, at 8 ohm, 10% THD
frequency bandwidth	500 Hz to 3000 Hz
input	Plug-in microphone (mini plug, mono)
output	Earphone (mini plug, mono) impedance is 32 ohm
speaker	Built-in 20 mm diameter
microphone	Built-in omni-directional elect condenser microphone (mono)
operating temperature	0°C to 40°C
accessory	Wrist Strap

Weight and Dimensions

dimensions	4.1 × 1 × 0.7 inches, 104 × 26 × 18 mm
weight (without batteries)	Approx. 34 g
