D9412G/D7412G Operation & Installation Guide
43488D Page 72 © 2002 Radionics
D9412G/D7412G
Appendix B: Point Address Charts
B.2 ZONEX 2, Points 129 to 247 (D9412G Only)
Place the labels on the base of the POPIT. Do not attach labels to the POPIT cover.
A number in the switch column indicates that the switch is set to ON.
Table 18: ZONEX 2 Point Address Chart
Switch Switch Switch
Address 0 1 2 3 4 5 6 Address 0 1 2 3 4 5 6 Address 0 1 2 3 4 5 6
129 0 1 2 3 4 5 6 169 0 2 4 5 6 209 1 3 4 5 6
130 0 1 2 3 4 5 170 0 2 4 5 210 1 3 4 5
131 0 1 2 3 4 6 171 0 2 4 6 211 1 3 4 6
132 0 1 2 3 4 172 0 2 4 212 1 3 4
133 0 1 2 3 5 6 173 0 2 5 6 213 1 3 5 6
134 0 1 2 3 5 174 0 2 5 214 1 3 5
135 0 1 1 3 6 175 0 2 6 215 1 3 6
136 0 1 2 3 176 0 2 216 1 3
137 0 1 2 4 5 6 177 0 3 4 5 6 217 1 4 5 6
138 0 1 2 4 5 178 0 3 4 5 218 1 4 5
139 0 1 2 4 6 179 0 3 4 6 219 1 4 6
140 0 1 2 4 180 0 3 4 220 1 4
141 012 56 181 0 3 56 221 1 56
142 0 1 2 5 182 0 3 5 222 1 5
143 0 1 2 6 183 0 3 6 223 1 6
144 0 1 2 184 0 3 224 1
145 0 1 3 4 5 6 185 0 4 5 6 225 2 3 4 5 6
146 0 1 3 4 5 186 0 4 5 226 2 3 4 5
147 0 1 3 4 6 187 0 4 6 227 2 3 4 6
148 0 1 3 4 188 0 4 228 2 3 4
149 0 1 3 5 6 189 0 5 6 229 2 3 5 6
150 0 1 3 5 190 0 5 230 2 3 5
151 0 1 3 6 191 0 6 231 2 3 6
152 0 1 3 192 0 232 2 3
153 0 1 4 5 6 193 1 2 3 4 5 6 233 2 4 5 6
154 0 1 4 5 194 1 2 3 4 5 234 2 4 5
155 0 1 4 6 195 1 2 3 4 6 235 2 4 6
156 0 1 4 196 1 2 3 4 236 2 4
157 0 1 5 6 197 1 2 3 5 6 237 2 5 6
158 0 1 5 198 1 2 3 5 238 2 5
159 0 1 6 199 1 2 3 6 239 2 6
160 0 1 200 1 2 3 240 2
161 0 23456 201 12 456 241 3456
162 0 2345 202 12 45 242 345
163 0 2 3 4 6 203 1 2 4 6 243 3 4 6
164 0 2 3 4 204 1 2 4 244 3 4
165 0 2 3 5 6 205 1 2 5 6 245 3 5 6
166 0 2 3 5 206 1 2 5 246 3 5
167 0 2 3 6 207 1 2 6 247 3 6
168 0 2 3 208 1 2 248*
* The panel reserves Point 248 for internal use.
