DefensePro User Guide
Monitoring DefensePro Devices and Interfaces
Document ID: RDWR-DP-V0602_UG1201 261
Monitoring and Clearing DefensePro Authentication Tables
You can view statistics for the device’s Authentication Tables. You can also clear the contents of each
table.
To monitor Authentication Tables for a selected DefensePro device
1. In the Monitoring perspective, select the Resource Utilization tab in the content pane.
2. Select Authentication Tables.
The following information is displayed:
Last 5 sec. Average
Utilization
Average utilization of resources in the last 5 seconds.
Last 60 sec. Average
Utilization
Average utilization of resources in the last 60 seconds.
Accelerator Utilization
Accelerator Type The name of the accelerator. The accelerator named
Flow_Accelerator_0 is one logical accelerator that uses several CPU
cores. The accelerator named HW Classifier is the string-matching
engine (SME). OnDemand Switch 3 S1 has no SME.
CPU ID The CPU number for the accelerator. OnDemand Switch 2 and
OnDemand Switch 3 S2 have two CPU cores. OnDemand Switch 3 S1
has three CPU cores.
Forwarding Task The percentage of CPU cycles used.
Other Tasks The percentage of CPU resources used for other tasks such as aging
and so on.
Idle Task The percentage of free CPU resources.
Parameter Description
TCP Authentication Table
Table Size The number of source addresses that the table can hold.
Table Utilization Percent of the table that is currently utilized.
Aging Time The aging time, in seconds, for the table.
Clear Table Click Clear Table to clear the contents of the table.
HTTP Authentication Table
Table Size The number of source addresses that the table can hold.
Table Utilization Percent of the table that is currently utilized.
Aging Time The aging time, in seconds, for the table.
Values: 60–3600
Default: 1200
Clear Table Click Clear Table to clear the contents of the table.
Parameter Description
