Rae PGM-7240 - Viewing Data (Datalog)

PROGRAMMING
- 52 -
4.6.1 Viewing Data (Datalogging)
This function allows the user to review all the data that is
stored in the non-volatile datalog memory.
Data is stored in groups or “events.” Each event consists of
the event time (hour : minute : second), and measurement
values.
For example:
Event/Log #1
Data #1 (10/01/97, 14:35:05, Avg., 0.2 PPM, Max 4.0)
Data #2 (14:35:10, Avg. 0.4, Max 11.0)
Data #3 (14:35:15, Avg. 0.4, Max 11.0)
Event/Log #2
Data #1 (10/03/98, 07:20:30, Avg. 3.4, Max 20.0)
Data #2 (07:20:40, Avg. 0.7, Max 20.0)
1. “View Data?” is the second sub-menu item in the
Datalog sub-menu.
2.
Press the [Y/+] key and the display shows “Event..” and
“Log #1?” (see figure below). Press the [Y/+] key to
view the data of the displayed event. Or press the [N/-]
key to scroll to next event. If there are no more events,
the message “No more events! Start from event #1?”
will appear. Press the [Y/+] key, the monitor will jump
back to the first event. Press the [N/-] key, the monitor
will remain in the last event.
3.
Press the [Y/+] key to review the first data of the
selected event. The display shows the stored data
including the time stamp in hours and minutes, and
measurement values.
