Rage Comet & Comet ‘R’ Maintenance Guide
Issue 2.0 October 2014
Intrax 4 - Way Adjustable Damper
C.
B
E.
A.
D.
A. Rebound:
When the damper is in the buggy, first turn the clicker clockwise to the right, this will
close the rebound fully. After this, start opening click by click. We close the rebound
first to be sure all dampers are working from the same starting point. When you close
the rebound this will make the buggy move (come back) slower to the normal position.
B. High speed compression:
Turn anti clockwise until adjuster stops; this is the softest position, with max. 50clicks.
With high speed compression hardness of the buggy can be controlled in a way you
can assist spring rate and make the buggy stiffer.
C. Low speed compression:
By turning clockwise low speed damping will increase (max. 18 clicks). With Low speed
the roll in buggy can be controlled and when in softer position (+- 10 clicks) small
bumps will be easier taken. (smoother drive)
D. 4th Adjustment
Low speed total damping curve adjustment. By turning the height of the housing from
the low-speed adjuster it is possible to change the start and the finish of the total
damping curve/force. Now the housing is 2 turns open from fully closed. By opening
anti clockwise ½ a turn low- speed curve will be softer over all clicks. If from 2 turns
out returning to 1 ½ turn, damping force will be higher overall clicks. Undo contra nut
with key 14 and turn house with key 9. Always have the adjuster needle fully open when
adjusting housing
E: Spring seat undo locknut before turning
