PARTS LIST RD-EBC05
Number Name Quantity
1 Motor fan 1
2 M4X60 Screw 2
3 Steel sleeve for motor fan 1
4 Motor bracket 1
5 Stator 1
6 Bearing 608 1
7 Rotor 1
8 Bearing 609 1
9 Bearing seat 1
10 Leak-proof cirle 1
11 Cable 1
12 Cable sheath 1
13 Right windshield 1
14 Right enclosure 1
15 4X16 tapping screw 11
16 4X14 tapping screw 2
17 Cable clamp 1
18 Left windshield 1
19 Left enclosure 1
20 Switch 1
21 M5X10 Screw 2
22 Soft start 1
23 Gear box 1
24 Carbon brush 2
25 Brush holder 2
26 M4X12 Screw 4
27 Switch hand 1
28 Reset spring of switch 1
29 Steel sleeve 1
30 3X10 woodruff key 1
31 Gear 1
32 Bearing 609 1
33 Bearing gland 1
34 4x10 Screw 3
35 Output shaft 1
36 Switch positioning block 1
37 Safety button 1
38 Reset spring of safety button 1
39 Limiting sleeve 2
40 Flexible shaft of power 1
41 Handle 1
42 Fix block of handle 1
43 5x25 inner hexagon screw 4
44 M5 nut 4
45 Alluminum tube 1
46 Fixing clip of support 2
47 Support tube forflexible shaft 1
Spare Parts List
