Programming the controller Rain Evo
In order to program Rain Evo you need only 3 buttons:
6
The Æ button (enter) to move from a screen to another one and to confirm
the set information.
6
The + button (incr.) to modify or increase data.
6
The , button (Man./Back) to confirm the weekly calendar, to active the
manual open and to come back to the previous screen.
Setting the Date and Time
Once batteries are connected, first the controller auto resets, than the display will appear as
the figure; the minutes icon starts flashing.
6
Press the + button to increase the units minutes
6
Press the Æ button and the tens minutes icon starts flashing.
6
With + button increase tens minutes
6
Follows the same procedure for hour unites and hour tens
6
Press the Æ button and the slash under the weekly days starts flashing
6
Press the + button to move the slash under the current day
6
Press the Æ button to confirm and proceed to the next operation
Note:
During programming session, after 20 seconds without pushing any button the controller will
come back to the first screen and will be saved only the confirmed information.
Setting Watering Start Times
6
Press the Æ button and the units minutes will flash.
6
Press the + button to set minutes units of first watering start times and fol-
low the same procedure to set the other units of current hour.
Setting Length of Watering
Leaving in OFF position the program, the area will be inactive.
Press the Æ button and the three zeros for the setting of the length watering will be
active .
6
The set of the length is in minutes (time minimum 1 min. - time maximum
360 min.)
6
Press the Æ button and the minutes units start flashing.
6
Set the length of watering following the usual procedure: + button to set
and Æ button to confirm and proceed to the next operation.
Note:
To reach the OFF position set at zero the length watering.
Setting Days to water
Choose the specific day in which irrigate:
6
Press the Æ button and the slash under the day starts flashing
6
Press the + button to move the slash under the day selected
6
Press the , button to change the current set up
Therefore:
, button to set or remove the watering days.
At the end press the Æ button to confirm all your settings and the
+ button
to come back to the main screen (current hour).
To change your settings press the Æ button and follow the procedure above
described.
Current day
Current hour
Watering Days
Now your controller is programmed and the display will appear as the figure
To change your setting:
6
Æ button to go into the setting
6
+
button to go in the screen you would change
Your settings
Irrigation
count down
Run Watering
The display appears as the figure during irrigation (count down).
Manual Watering
6
Press the , button to open manually the valve.
6
To change the minutes of watering, press the + button and confirm with Æ
button.
6
Otherwise after 20 sec., the controller will start automatically with the 3 minu-
tes of watering.
6
Press , button to stops the manual watering.
Rain Evo has set a manual watering of 3 minutes, to change the length press the
+ button and modify the setting,
from minimum 1 min. to maximum of 360 min.
1 2
3 4
I and II irrigation
Note:
To get midnight you should set 00 as time and not 24.
Note:
To get midnight you should set 00 as time and not 24.
