14 Raket 95 Manual - English
6. Technical data for Raket 95
Engine model One-cylinder two-stroke engine of Dual Charge model
Cylinder volume 94 cm3
Cylinder diameter 56 mm
Stroke 38 mm
Connecting rod length 74 mm
Carburettor Tillotson HS 319 a, venturi 17,7 mm
Ignition system Selettra analog
Flywheel Selettra 113,9 mm
Starter system Electric, integrated starter (or Magnapull cord starter)
Starter battery Raket, 14.4 V Nickel-metal hydride (NiMH) 3.0 Ah
Spark plug NGK BPM 8 Y
Clutch Centrifugal clutch metal
Sprocket on clutch drum 11 teeth, type 219
Exhaust system Tuned system with end silencer
Fuel Alkylate or 95/98 octane lead free petrol
Petrol mix 4% of synthetic two-stroke oil
Squisch Min 0,8 mm
Combustion chamber volume Min.11,0 ml
Bearings Original SKF 6203 TN9C3
Sealing rings 17x28x7 sealing lip with Teon coating and dust seal
Idling speed 2500 rpm
Max rpm 12500 rpm
Max power 7,6 kW at 8600 rpm
Recyclable parts in the engine 82 %
Emission values CO and HC According to EPA2 standards
Weight 12.1 kg complete engine (engine, starter battery and
silencer)
