Circuit Function Fuse Wire Color Location
* If Equipped
Aux Switch 6* F20 – 20 Amp Pink/Yellow Underhood PDC
Interior Bulbs
Bulb Name Bulb Number
Overhead Console Lam
ps TS 212–9
Dome Lamp 7679
NOTE: For lighted switches, see an authorized dealer for replacement instructions.
Exterior Bulbs
Bulb Name Bulb Number
Low & High Beam (LED Reflector Headlamp) LED
Low & High Beam (LED Projector Headlamp) LED
Turn Signal / Front Position (LED Reflector Headlamp – If Equipped) 7444NA
Turn Signal / Front Position (LED Projector Headlamps – If Equipped) LED
Front Side Marker LED
Front Fog Lamps LED
Side Indicators (Front And Side View Mirror – If Equipped) LED
Base Rear Tail/Turn and Stop Lamp 7440LL/W21WLL
Premium Rear Tail/Turn/Backup and Stop Lamp LED
Base Backup Lamp 7440/W21W
Center High Mounted Stop Lamp (CHMSL) 921
Cargo Lamp 921
Rear License Plate Lamp LED
Base Turn Lamp 7440NA / WY21W
SERVICING AND MAINTENANCE 329
8
BULB REPLACEMENT
Replacement Bulbs, Names, And Part Numbers
In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. All of the inside bulbs are brass or glass-wedge base.
Aluminum base bulbs are not approved.
NOTE:
See an authorized dealer for LED bulb replacement.
