Cavity Cartridge Fuse Micro Fuse Description
F22 20 Amp Blue
30 Amp Pink (Cum-
mins Diesel)
– Engine Control Module
F23 30 Amp Pink – Body Controller #1 / Interior Lighting
F24 30 Amp Pink – Driver Door Module
F25 30 Amp Pink – Front Wiper
F26 30 Amp Pink – Antilock Brakes / Stability Control Module /
Valves
F28 20 Amp Blue – Trailer Tow Backup Lights – If Equipped
F29 20 Amp Blue – Trailer Tow Parking Lights – If Equipped
F30 30 Amp Pink – Trailer Tow Receptacle
F31 30 Amp Pink (1500
LD Diesel)
– Urea Heater Control – If Equipped
F32 – – Spare Fuse
F33 20 Amp Blue – Special Services Vehicle Only
7
MAINTAINING YOUR VEHICLE 845
