The vehicle is close to the obstacle when the warning
display shows one flashing arc and sounds a continuous
tone. The following chart shows the warning alert opera-
tion when the system is detecting an obstacle:
WARNING ALERTS
Rear Distance
(inches/cm)
Greater than
79 inches
(200 cm)
79-45 inches
(200-115 cm)
45-31 inches
(115-80 cm)
31-18 inches
(80-45 cm)
Less than
18 inches (45 cm)
Audible Alert
Chime
None Single 1/2
Second Tone
Slow Fast Continuous
Fast Tone Continuous Tone
400 STARTING AND OPERATING
