Cavity
Cartridge
Fuse
Mini Fuse Description
J13 60 Amp Yellow Main Ignition Off Draw (IOD)
Fuse
J14 20 Amp Blue Trailer Tow Lamps/Park
Lamps
J15 40 Amp Green Front Blower
J17 40 Amp Green Starter Motor Solenoid
J18 20 Amp Blue Powertrain Control Module
Transmission Range
J19 60 Amp Yellow Rad Fan Motor HI/Rad Fan
Motor Low
J20 30 Amp Pink Front Wiper Ground/Low/High
J21 20 Amp Blue Washer Control
J22 25 Amp
Natural
Sunroof Module
M1 15 Amp Blue Stop Switch Lamp
M5 25 Amp
Natural
115V AC Inverter
M6 20 Amp Yellow Power Outlet (Instrument
Panel or Front Console)/Rain
Snsr
M7 20 Amp Yellow Power Outlet (Rear Console or
Center Seat)
M8 20 Amp Yellow Front Heated Seat & Steering
Wheel
M9 20 Amp Yellow Rear Heated Seats
M10 15 Amp Blue Hands Free Module/Vanity
Lamp/Universal Garage Door
Opener Module
M11 10 Amp Red Climate Control System
M12 30 Amp Green Radio/Amplifier
M13 20 Amp Yellow Main #2 Instrument
Cluster/Wireless Control
Module/ITM/Siren/
Multifunction Switch (Steering
Column Module)
M14 20 Amp Yellow Back Up Camera (Domestic
Only)
M15 20 Amp Yellow Power Seat Module(s)/Audio
Telematics/Daytime Running
Lights Relay/Instrument
Cluster/Transfer Case Module
M16 10 Amp Red Airbag Module
M18 15 Amp Blue Center Stop Lamp
M19 25 Amp
Natural
Automatic Shutdown 1 and 2
