FM30• 13
1 47nF or 0.047uF ceramic disc capacitor (marked 473) (C34)
2 47pF ceramic disc capacitors (marked 47) (C67,70)
1 75pF ceramic disc capacitor (marked 75) (C66)
5 100pF ceramic disc capacitors (marked 101) (C16,25,28,44,50)
2 150pF ceramic disc capacitors (marked 151) (C31,40)
2 560pF ceramic disc capacitors (marked 561) (C23,45)
2 3300pF ceramic disc capacitors (marked 332) (C30,39)
3 100uF electrolytic capacitors (C13,38, R5[no kidding!])
12 10uF electrolytic capacitors (C1,9,10,11,15,21,27,29,41,42,47,51)
MISCELLANEOUS
1 28 pin socket (for U1)
1 PCB Mounted BNC connector (J9)
1 2x8 line LCD display (DS1)
1 14-pin dual row connector (for DS1)
1 DPDT Power switch (S1)
6 2.2uH inductors (green body, red-red-gold-silver) (L1,2,3,4,5,6)
2 4 turn air core inductors (L8,9)
1 2.1mm center post positive power jack (J3)
2 RCA audio jacks (J8,J10)
2 8-pin dual row connectors (J2,5)
1 Mini speaker (SP1)
3 Momentary buttons (S2,3,4)
1 7.6MHz Crystal (Marked 7.600) (X1)
1 Switch cap
Case Top & Bottom, screws for case
Front and rear panels
1 15VDC power supply
1 Whip antenna
SURFACE MOUNT PARTS, PREINSTALLED
1 BBY40 Varactor diode. SOT23 package (marked S2) (D5)
1 1SV172 Pin Diode. SOT package. (Strange B and E marking) (D8)
2 0.1uF ceramic surface mount capacitors (C18,35)
2 470pF ceramic surface mount capacitors (C19,20)
1 BH1415F Stereo Modulator IC (U3)
2 10K ohm surface mount resistors (marked 103) (R12,13)
1 TC1320EOA Digital to analog converter (U7)
1 GAL5 DC-8GHz monolithic RF amplifier (U8) Marked o5
