FR146 2 Meter FM Receiver Kit
Quick Reference Page Guide
I
ntroduction to the FR146 ............... 4
Circuit Description .......................... 5
Parts List ........................................ 6
Simplified Block Diagram ............... 8
Parts Layout Diagram .................... 9
FR146 Assembly Instructions ........10
Testing and Alignment ...................18
Enclosure Ideas ..............................20
Troubleshooting Guide ...................21
Notes for Advanced Users .............21
Ramsey Kit Warranty .....................23
Price: $5.00
Ramsey Publication No. FR-146
Assembly and Instruction manual for:
RAMSEY MODEL NO. FR146 2 METER FM RECEIVER KIT
REQUIRED TOOLS
• Soldering Iron Ramsey WLC100
• Thin Rosin Core Solder Ramsey RTS12
• Needle Nose Pliers Ramsey MPP4 or
RTS05
• Small Diagonal Cutters Ramsey RTS04
<OR> Technician’s Tool Kit TK405
ADDITIONAL SUGGESTED ITEMS
• Holder for PC Board/Parts Ramsey HH3
• Desoldering Braid Ramsey RTS08
• Digital Multimeter Ramsey M133
TOTAL SOLDER POINTS
232
ESTIMATED ASSEMBLY
TIME
Beginner ............... 6.8 hrs
Intermediate ......... 3.9 hrs
Advanced ............. 2.9 hrs
