This sheet only guides the requirements of the installation for stainless quick connector
pipe.Other installation requirements please refer to the installation guide along with the
unit.
11
INSTALLATION & REPAIR GUIDE
Split Wall-Mounted air conditioner
*
To expand the connecting pipe,please hold one side then expand it following the right direction.
*
Please insure the angles have a radian at some extent while intalling the stainless soft pipe.
Angels need to be around, not bended.(to the quick connecting spot and drilled point of wall.
*
Please fix the stainless soft pipe while installing because the connecting pipes are soft, so that
prevent them from getting bended or stretched.
*
The minimum bending radius are as follows:
Minimum bending radius(mm)
Twenty-one,Twenty-five
Thirty-five
Model
One hundred and fifteen(mm)
One hundred(mm)
Stainless soft pipe
*Quick connector installation instruction *
*Eight
*Ten
*Thirteen
fifty-one
Eighty(mm)
