Owner / Operator’s Responsibility
It is the owner / operator’s responsibility to:
1. Carefully read and understand the entire Operation & Maintenance Manual along
with the assembly instructions.
2. Be certain that all assembly procedures are followed as described in the following
instructions.
3. Fill the equipment with the proper fluids before starting as described in the Opera-
tion & Maintenance Manual and the engine manufacturer’s manual.
4. Operate the log splitter according to safe operating procedures as spelled out in
the Operation & Maintenance Manual and these
assembly instructions.
5. Perform all required maintenance as di-
rected in the Operation & Maintenance Manual,
the engine manufacturer’s manual, and these as-
sembly instructions.
Unpacking Loose Parts
The log splitter assemblies and parts are secured
with metal bands. Carefully cut the metal bands
with a pair of tin snips. Remove all parts from the
skid and lay out in a clean, unobstructed area. Do not discard packing materials until the
machine is completely assembled to avoid accidentally discarding machine parts. The parts
you should have but not limited to be as follows:
Log splitter Beam Assembly
Hydraulic Tank / Axle Frame assembly
Tires and necessary hardware to install as
described in this procedure
Valve Handle Assembly
Operation and Maintenance Manual
Gasoline Engine Manual No Manual for
Electric Models
Tools Required: Adjustable wrench,
pliers and a standard S.A.E Socket set.
For full check list see page 24
