Randall UnIOn lOc k -StItch
Installation
Since 1858
Since 1858
www.Campbell-Randall.com
3
Wax Pot
• Place the wax pot over the stuf on the back of the
machine
• Pivot the wax pot up to the the machine casting and lock
in place with the clamping nut.
Presser Foot Spring
• Place the upper bracket and spring on top of the machin
head
• With the left hand, compress the coil spring and push the
bracket into the hole in the casting.
• With the right hand, secure the bracket in place by
tightening the screw with a slotted screw driver.
