Physiolaser olympic 500
Version 1.4 June 2007
9
Explanation of the pictograms
IP21
Equipment rating against harmful ingress of water as
defined in IEC529. (see std. 60601-1 clause 6.1(L) )
Protection against electric shock regarding allowable
leakage current limitations are specified in standard
60601-1.
0123
The device meets the requirements of 93/42/EEC for
medical products.
“Attention” Observe the instructions in the manual for
safe and effective usage of this device.
Symbol for the laser beam: ”Warning for laser beam”.
Explanatory Label Symbol (International):
" Visible and invisible laser radiation" including the
standard which was used for the classification of the
laser.
Singel probe
Multi cluster probe
Labels according to EN 60825-1:
- Laser aperture and laser beam direction
Type plate with technical data and address of the
manufacturer
