AC power supply connector
Trigger input/
external reference input
Generator output, N connector
Power sensor connector
RF input, N connector
Headphones connector
¸FSH 3 ¸FSH 6
Frequency range 100 kHz to 3 GHz 100 kHz to 6 GHz
Resolution bandwidths 1 kHz to 1 MHz (model .13)
100 Hz to 1 MHz (models .03 and .23)
100 Hz to 1 MHz
Video bandwidths 10 Hz to 1 MHz
Displayed average noise level typ. –114 dBm (1 kHz) (model .13)
typ. –135 dBm (100 Hz) (models .03 and .23)
typ. –135 dBm (100 Hz)
TOI typ. 13 dBm
SSB phase noise <–100 dBc (1 Hz) at 100 kHz from carrier
Detectors sample, max/min peak, auto peak, RMS
Level measurement uncertainty <1.5 dB, typ. 0.5 dB
Reference level –80 dBm to +20 dBm
Dimensions 170 mm × 120 mm × 270 mm
Weight 2.5 kg
Data in brief
