Rane ONE - Page 16

..2 TWPC19C02701 Fader PCB Assembly 1
...3 TWPC19C02701M Fader PCB DIP Assembly 1 -
....4 TE591271001 Pin Header 180° Pitch:1.27mm 1 (J1)
...3 TWPC19C02701T Fader PCB SMT/AI Assembly 1 -
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 14 C2,3,4,5,6,7,8,9,10,11,14,15,17,18
....4 CS106K1003X5R CCAP SMD 10uF 10% 10V 0603 X5R 4 C1,12,13,16
....4 ICA1324LLHLX-T IC SENSOR HALL EFFECT 4 U1,2,3,4
....4 ICLP3990MF-3.3 LP3990MF-3.3/NOPB SMD 1 U6
....4 ICTPS73601DCQ IC TPS73601DCQ Low-Dropout Reg 1 U7
....4 ICYHFRC327 IC LPC824M201JDH+Program 1 U5
.....5 ICLPC824M201JDH IC Uc lpc824 32bit 32k lash arm 1 -
....4 PC19C0027 Fader PCB 1 -
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R6
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 5 R8,9,10,11,12
....4 RS015K10F03 RESISTOR 15K 1% SMD 0603 1 R13
....4 RS030110F03 RESISTOR 301 1% 1/10W 0603 1 R7
....4 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R5
....4 RS2K2110F03 RESISTOR 2.21K 1% SMD 0603 4 R1,2,3,4
....4 RS4K9910F03 RESISTOR 4.99K 1% SMD 0603 1 R14
....4 TE6A2000601 Pin Header 90° Pitch 2.0mm Single 1 (J2)
....4 UHHZ0603B102R Bead 1000 ±25% 200mA 0603 3 L1,2,3
0.1 TWPC19C01401 RIGHT PCB Assembly(SMT/DIP) 1 39
..2 TWPC19C01401T RIGHT PCB SMT/AI Assembly 1
...3 PC19C014 RIGHT PCB 1
...3 TWPC19C014A01T RIGHT PCB Assembly(SMT) 1 -
....4 AL0-17-8103 RESISTOR ARRAY 8X10K 4 RN1,2,3,4
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C14,19
....4 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 1 C20
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 19
C1,2,3,4,5,6,7,8,9,10,11,12,13,15,17,18,23,
25,26
....4 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1 C24
....4 CS226M3505X5R CCAP SMD 22uF/35V 20% 0805 X5R 2 C21,22
....4 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 1 C16
....4 FCN1T1000401 FCN Up Touch ZIF SMD 1 J1
....4 FCN1T1001402 FCN DOWN Touch ZIF SMD 1 J3
....4 FCN2T1002002 FCN Dual Touch 180° SMD 1 J2
....4 IC74AHC1G14DBVR IC 74AHC1G14DBVR 1 U1
....4 ICMCP6002I-SN IC OPAMP MCP6002I/SN(S08) 1 U14
....4 ICSN74HC165DR IC SHIFT REGISTER SN74HC165DR 4 U4,7,10,13
....4 ICSN74HC595DR IC SN74HC595DR 8-Bit Shit Reg 9 U2,3,5,6,8,9,11,12,15
....4 LD6703ARQHGRBYW Liquid-emitting Diode Red/Gree 13 LED1,2,3,4,6,7,8,9,10,11,12,13,14
....4 LDC191TBKT-5A Liquid-emitting Diode Blue SMD 3 D2,6,9
....4 LDKPT-1608SECK Liquid-emitting Diode amber SM 3 D12,13,14
....4 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 9 D8,18,19,20,21,22,23,24,25
....4 LDL-S291SWC-ML5 LED White SMD 0603 120° 10 D1,3,4,5,7,10,11,15,16,17
....4 RS000010J03 RESISTOR 0 5% SMD 0603 2 R67,84
....4 RS010010F03 RESISTOR 100 1% SMD 0603 4 R14,56,59,62
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 3 R68,69,72
....4 RS015010F03 RESISTOR 150 1% SMD 0603 48
R3,4,6,7,9,10,12,13,21,22,24,25,27,28,30,3
1,36,37,39,40,42,43,48,49,51,52,53,54,55,5
8,60,61,64,65,73,74,75,76,77,78,79,80,85,8
6,87,88,89,90
....4 RS030110F03 RESISTOR 301 1% 1/10W 0603 13 R2,5,8,11,20,23,26,29,35,38,41,44,50
....4 RS051110F03 RESISTOR 511 1% SMD 0603 1 R82
....4 RS1K2410F03 RESISTOR 1.24K 1% SMD 0603 1 R71
....4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 13 R1,17,18,19,32,33,34,45,46,47,57,63,66
....4 RS4K7510F03 RESISTOR 4.75K 1% SMD 0603 1 R81
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm S 1 (J4)
....4 UHBLM18BD121SN1 IND BEAD 120 100MHz 200mA 0.40 3 L1,2,3
...3 TWPC19C014C01T RIHGT FRONT PCB SMT ASSEMBLY 1
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C103,105
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 1 C100
