Rane ONE - Page 17

....4 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R 2 C102,104
....4 DISMBJ9.0CA DIODE P6SMB11CAT3 BRKDWN TVSC 2 D100,101
....4 FCN2T1000801 FCN Dual-Contact Vertical SMD 1 J100
....4 OTM21CC222R1H3 NETWORK EMI Suppression Filters 2200pF 2 FIL100,101
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 1 R102
...3 TWPC19C014D01T Start/Stop PCB SMT/AI Assembly 1
....4 AL2-54-0138 Moset BSS138 N-CH 3 Q200,201,202
....4 LD6703ARQHGRBYW Liquid-emitting Diode Red/Gree 2 LED200,201
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 3 R200,201,202
....4 RS015010F03 RESISTOR 150 1% SMD 0603 4 R204,205,207,208
....4 RS030110F03 RESISTOR 301 1% 1/10W 0603 2 R203,206
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm 1 (J200)
..2 TWPC19C014A01 RIGHT PCB Assembly(DIP) 1
...3 MT070446701 IRON PLATE 1 (ENC1)
...3 SWEN11-HSB1AF15 Switch Rotational Encode 20Pul 1 ENC1
...3 SWEVQ11Y05B Switch Tact Stem Heigh:5mm Ope 14
SW15,16,17,18,19,20,21,22,23,24,25,26,27,
28
...3 VRR10301558 Potentiometer Rotary Volume:10K2B 1 R70
...3 VRS10310022 Potentiometer Slide 10KB 100mm 1 R83
..2 TWPC19C014B01 Shielding PCB Assembly 1 73
..2 TWPC19C014C01 RIHGT FRONT PCB DIP ASSEMBLY 1 76
...3 JK6HTJ064-12DMP Phone Jack 6.3f 3Pin 90° DIP 1 J102
...3 JKK3J13B-5 3.5fHeadphone Jack 5pim 90° 1 J103
...3 SWSSSS914500 Switch Slide Single Row 3P 2T 1 S100
...3 TE622000401 Pin Header 90° Pitch:2.00mm 1 (J101)
...3 VRR10301560 Potentiometer Rotary Volume:10K2B 2 R100,101
..2 TWPC19C014D01 Start/Stop PCB DIP Assembly 1 54
...3 SWDF-03S-6P-M-Z Micro switches SWDF-03S-6P-M-Z 1 SW200
0.1 TWPC19C01501 FRONT PCB Assembly(SMT/DIP) 1 74
..2 TWPC19C01501M LEFT FRONT PCB DIP ASSEMBLY 1
...3 SWSSSS914500 Switch Slide Single Row 3P 2T 4 S2,4,5,7
...3 SWSSSS91A601 Switch Slide 1P3T 90° 1 S3
...3 VRR10301560 Potentiometer Rotary Volume:10K2B 4 R3,6,9,11
...3 VRR10301561 Potentiometer Rotary Volume:10K2B 4 R4,5,7,8
..2
TWPC19C01501T FRONT PCB SMT/AI Assembly 1
...3 AL2-73-4051 IC74HC4051 Single 8-Chan 1 U1
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 8 C3,4,5,6,7,8,9,25
...3 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R 3 C1,11,12
...3 CS226M3505X5R CCAP SMD 22uF/35V 20% 0805 X5R 2 C13,14
...3 FCN2T1000801 FCN Dual-Contact Vertical SMD 1 J1
...3 FCN2T1001801 FCN Dual Touch 180° SMD 1 J6
...3 PC19C015 FRONT PCB 1 -
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 6 R12,16,17,18,19,21
0.1 TWPC19C01601T FSR PCB Assembly(SMT) 2 38
..2 FCN2T1001401 FCN Dual Touch Pitch:1.0mm 14P 2 (J1)
..2 PC19C016 FSR PCB 2 -
0.1 TWPC19C01701 MAIN PCB Assembly(SMT/DIP) 1 48
..2 TWPC19C01701M MAIN PCB Assembly(DIP) 1
...3 AL4-05-0028 JACK XLR 3-PIN FEM STEREO-COMB 2 J3,5
...3 FS1028501SEU Round Fuse 372-1100-0001 1.0A/ 1 F3
...3 FS162250VTR5 FUSE T 1.6A 250V TR5 RAD 2 F1,2
...3 JK0KUSBXHTBS1NO B-TYPE USB Jack 90° (Orange) 2 J20,22
...3 JK4KRJ204AE6324 RCA JACK 6P 90° PIN WHITE/RED 4 J1,2,4,9
...3 JKANC3MAH XLR JACK 3Pin 90° Male 4 J6,7,8,21
...3 SWDS-11L-C2 Switch Slide 2P2T 2 S1,2
