Rane ONE - Page 18

...3 SWVS6P001 Switch Slide 2P2T 1 S3
...3 TE102251 Block(2P) 2 (J15,17)
...3 TE612000202 Terminal 2P 2.0 180° 2 (J18,33)
...3 TE613960201 Connector 2P 180 2 (J29,30)
...3 TE613960601 Connector 6P 180 1 (J32)
..2 TWPC19C01701T MAIN PCB Assembly(SMT) 1
...3 AL2-54-0138 Moset BSS138 N-CH 3 Q29,30,31
...3 CS068C5002NPO CCAP SMD 6.8PF/50V ±0.25PF 0402 NPO 2 C247,248
...3 CS101J5002NPO CCAP SMD 100pF/50V 5% 0402 NPO 13
C198,199,200,201,202,203,249,250,252,25
3,254,311,314
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C80,95,101,116
...3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 2 C162,246
...3 CS104J2506NPO CCAP SMD 0.1UF/25V 5% 1206 NPO 8 C83,85,96,98,105,107,117,122
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 87
C5,6,10,11,12,18,20,23,24,28,35,39,40,42,5
2,53,54,55,58,59,60,61,62,67,68,69,70,71,7
2,82,86,103,104,118,119,120,123,124,125,1
28,129,134,135,136,138,139,142,144,148,1
49,150,151,154,155,156,159,165,167,169,1
70,172,179,180,188,189,196,207,209,210,2
61,264,265,266,269,271,272,274,275,284,2
85,287,290,292,293,294,295,317
...3 CS105K1605X7R CCAP SMD 1uF/16V 10% 0805 X7R 6 C17,57,126,145,158,316
...3 CS105K2503X7R CCAP SMD 1UF/25V ±10% 0603 X7R 2 C257,258
...3 CS105M0602X5R CCAP SMD 1uF/6.3V ±20% 0402 X7R 1 C243
...3 CS106K1005X7R CCAP SMD 10uF/10V 10% 0805 X7R 6 C63,64,65,161,190,191
...3 CS106M1003X5R CCAP SMD 10uF 20% 10V 0603 X5R 4 C78,99,215,260
...3 CS120J5003NPO CCAP SMD 12P 5% 50V 0603 NPO 2 C81,102
...3 CS121J5003NPO CCAP SMD 120pF/50V 5% 0603 NPO 4 C89,91,110,112
...3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 10 C298,299,302,303,304,305,306,307,308,309
...3 CS221J5002NPO CCAP SMD 220PF/50V ±5% 0402 NPO 4 C310,312,313,315
...3 CS221J5003NPO CCAP SMD 220pF/50V 5% 0603 NPO 4 C74,75,76,77
...3 CS222J5003NPO CCAP SMD 2200P 50V 5% 0603 NPO 2 C182,267
...3 CS224K1602X7R CCAP SMD 220NF/16V 10% 0402 X7R 34
C164,195,197,205,206,213,218,219,220,22
1,223,224,225,227,229,231,233,234,236,23
9,241,242,244,245,251,255,256,259,276,27
7,278,279,280,281
...3 CS226K1006X5R CCAP SMD 22uF/10V 10% 1206 X5R 5 C3,4,9,56,130
...3 CS226M0603X5R CCAP SMD 22uF/6.3V 20% 0603 X5R 3 C214,216,237
...3 CS226M3505X5R CCAP SMD 22uF/35V 20% 0805 X5R 7 C168,208,211,212,270,300,301
...3 CS272J5003NPO CCAP SMD 2.7nF/50V 5% 0603 NPO 8 C13,14,29,30,45,46,66,73
...3 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 6 C15,16,31,32,47,48
...3 CS331J5005NPO CCAP SMD 330pF/50V 5% 0805 NPO 12 C1,2,7,8,21,22,25,26,33,34,43,44
...3 CS332J5005NPO CCAP SMD 3.3nF/50V 5% 0805 NPO 6 C163,174,177,183,186,193
...3 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO 16
C27,37,41,50,90,94,111,114,127,132,137,1
41,146,147,152,153
...3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 4 C282,288,289,297
...3 CS475M0602X5R CCAP SMD 4.7uF 20% 6.3V 0402 X5R 9 C217,222,226,228,230,232,235,238,240
...3 CS476M0606X5R CCAP SMD 47u/6.3V 20% 1206 X5R 2 C88,109
...3 CS681J5003NPO CCAP SMD 680pF/50V 5% 0603 NPO 12
C160,166,173,175,176,178,181,184,185,18
7,192,194
...3 CS683J5006NPO CCAP SMD 68nF/50V 5% 1206 NPO 4 C84,97,106,121
...3 CS821J5003NPO CCAP SMD 820pF/50V 5% 0603 NPO 8 C36,38,49,51,131,133,140,143
...3 DIBAT54 Schottky Barrier Rectiies Diode BAT54 4 D29,30,31,32
...3 DIENMMBD4148SE Diode Single MMBD4148SE 100V 200mA 2 D5,12
...3 DIESD5B5.0S Transient Voltage Suppressor Diode ESD5B 4 D6,10,13,18
...3 DIMBRS140T3G Schottky diode MBRS140T3G 40V 3 D28,55,57
...3 DIMMBZ5231B Zener diodes MMBZ5231B 5.1V/ 0.02A 1 D56
...3 DIMURS160 ULTRAFAST RECTIFIERS 1A 2 D35,37
...3 DISDBAT54SSM Diode BAT54S 30V 0.2A 22
D1,2,7,11,14,17,19,22,26,38,39,40,41,42,43
,44,45,46,47,48,49,50
...3 DISDMBRA340T3G
Shottky diode DISDMBRA340T3G SMD 3A 40V
1 D36
