Rane ONE - Page 20

...3 RS1K2410F03 RESISTOR 1.24K 1% SMD 0603 2 R103,135
...3 RS22R108F05 RESISTOR 22.1 1% SMD 0805 16
R7,8,20,21,29,30,47,48,55,56,68,69,79,80,8
1,82
...3 RS22R116F02 RESISTOR 22.1 1% SMD 0402 7 R258,259,260,261,265,266,318
...3 RS23K710F03 RESISTOR 23.7K 1% SMD 0603 2 R289,294
...3 RS2K2110F03 RESISTOR 2.21K 1% SMD 0603 6 R119,121,151,153,291,297
...3 RS2K2116F02 RESISTOR 2.21K 1% SMD 0402 2 R274,275
...3 RS2K4908F05 RESISTOR 2.49K 1% SMD 0805 42
R33,36,40,73,74,158,159,160,167,177,178,
182,187,189,190,196,198,199,207,208,211,
214,215,217,220,222,225,226,229,234,235,
237,239,241,242,243,245,247,250,252,255,
257
...3 RS2K4910F03 RESISTOR 2.49K 1% 1/10W SMD 0603 4 R94,99,126,130
...3 RS2M2110F03 RESISTOR 2.21M 1% SMD 0603-RoHS 1 R319
...3 RS30K116F02 RESISTOR 30.1K 1% SMD 0402 1 R304
...3 RS33R208F05 RESISTOR 33.2 1% SMD 0805 2 R173,175
...3 RS39K210F03 RESISTOR 39.2K 1% SMD 0603 1 R295
...3 RS39R204F06 RESISTOR 39.2 1% SMD 1206-RoHS 4 R102,116,136,150
...3 RS3K1604F06 RESISTOR 3.16K 1% SMD 1206 1 R236
...3 RS3K3210F03 RESISTOR 3.32K 1% SMD 0603 6 R105,111,139,145,271,298
...3 RS3K7410F03 RESISTOR 3.74K 1% SMD 0603 4 R100,106,133,138
...3 RS45K310F03 RESISTOR 45.3K 1% SMD 0603 2 R270,293
...3 RS47K510F03 RESISTOR 47.5K 1% SMD 0603 4 R95,120,129,154
...3 RS47K516F02 RESISTOR 47.5K 1% SMD 0402 2 R333,334
...3 RS49R916F02 RESISTOR 49.9 1% SMD 0402 14
R19,22,272,273,278,279,282,283,286,287,3
00,301,302,303
...3 RS4K0208F05 RESISTOR 4.02K 1% SMD 0805 24
R3,4,9,10,13,14,15,16,25,26,31,32,41,42,43
,44,51,52,57,58,61,62,64,65
...3 RS4K3210F03 RESISTOR 4.32K 1% SMD 0603 6 R63,162,168,183,188,197
...3 RS4K7510F03 RESISTOR 4.75K 1% SMD 0603 2 R203,205
...3 RS51R104F06 RESISTOR 51.1 1% SMD 1206 4 R193,195,200,206
...3 RS5K1108F05 RESISTOR 5.11K 1% SMD 0805 8 R83,84,85,86,87,88,89,90
...3 RS5K7610F03 RESISTOR 5.76K 1% SMD 0603 1 R292
...3 RS8K0610F03 RESISTOR 8.06K 1% SMD 0603 1 R269
...3 RS90R908F05 RESISTOR 90.9 1% SMD 0805 16
R5,6,17,18,27,28,45,46,53,54,66,67,343,34
7,351,354
...3 TCS336M100B Electrolytic Capacitors 33uF/10V 20% SMD 4 C171,262,263,268
...3 TE591271001 Pin Header 180° Pitch:1.27mm 1 (J14)
...3 TE5A2540601 Pin Header 180° Pitch:2.54mm 1 (J16)
...3 TE6A2000401 Pin Header 180° Pitch 2.0mm 1 (J10)
...3 TE6A2000602 Pin Header 180° Pitch 2.0mm 1 (J31)
...3 TR2SD2704 TRANSISTOR 2SD2704 16
Q3,8,11,16,17,18,19,20,21,22,23,24,25,36,3
7,38
...3 TRBC857BMGT116 Tramsistor BC857BMGT116 8 Q4,5,6,7,12,13,14,15
...3 TRBSS84 Moset BSS84 P-CH SOT-23 2 Q27,28
...3 TRFMMT2222A XSTR 2222A SW NPN 40V 600mA 1 Q39
...3 TRMMBT2907ALT1 Transistor MMBT2907ALT1 PNP 5 Q1,2,9,10,26
...3 UHACM2012900-2P Chock 90 0.4A 2.0X1.2mm 2 L6,8
...3 UHBLM18AG102SN1 BEAD 1000 100MHZ 4 FB1,2,3,4
...3 UHBLM18BD121SN1 IND BEAD 120 100MHz 200mA 5 L2,3,24,25,26
...3 UHDRQ127-470-R Inductor 47uH 2.95A 20% SMD 1 L15
...3 UHH55DN100M03L CHOKE 10uH 1.7A 20% 2220-SMD 2 L12,16
...3 UHHS505040T4R7M Inductor 4.7uH 3.78A Irms2.88A 1 L1
...3 UHHZ0603B102R Bead 1000 ±25% 200mA 0603 2 L4,7
...3 UHPA2745NL Common Inductor 6.75 +/-30% 2 L13,14
...3 UHPID1207-220M Inductor SMD 22UH 1 L9
...3 XTM24000X8 Crystal 24MHz 3.2*2.5*1.0MM SM 1 X2
0.1 TWPC19C01801 LEFT PCB Assembly(SMT/DIP) 1
..2 TWPC19C01801T LEFT PCB SMT/AI Assembly 1 -
...3 PC19C018 LEFT PCB 1 -
...3 TWPC19C018A01T LEFT PCB Assembly(SMT) 1
....4 AL0-17-8103 RES ARRAY 8X10K 8 RN1,2,3,4,5,6,7,8
