....4 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 1 3 U10,11,13
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 23
C12,13,14,15,16,17,18,27,28,29,30,31,32,4
3,44,45,46,47,48,49,50,67,72
....4 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 1 C73
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 51
C1,2,3,4,5,6,7,8,9,11,19,20,21,22,23,24,25,
26,33,34,35,36,37,38,39,40,41,42,51,52,53,
54,55,56,57,58,59,60,61,62,63,64,65,66,68,
70,71,87,88,89,90
....4 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 11 C76,77,78,79,80,81,82,83,84,85,86
....4 CS226M3505X5R CCAP SMD 22uF/35V 20% 0805 X5R 2 C74,75
....4 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 1 C69
....4 ECS10716DLE ECAP Low ESR 100uF/16V 6.3*5.5mm SMD 1 C10
....4 FCN1T1000401 FCN Up Touch ZIF SMD 1 J9
....4 FCN1T1001402 FCN DOWN Touch ZIF SMD 1 J3
....4 FCN2T1001801 FCN Dual Touch 180° SMD 1 J10
....4 FCN2T1002002 FCN Dual Touch 180° SMD 1 J7
....4 FCN2T1003003 FCN Dual Touch Pitch=1.0mm 30P 1 J5
....4 IC74AHC1G14DBVR IC 74AHC1G14DBVR 2 U5,17
....4 ICMCP6002I-SN IC OPAMP MCP6002I/SN(S08) 1 U30
....4 ICSN74HC165DR IC SHIFT REGISTER SN74HC165DR 8 U6,7,8,9,20,23,26,29
....4 ICSN74HC595DR IC SN74HC595DR 8-Bit Shit Reg 15 U1,2,3,4,12,18,19,21,22,24,25,27,28,31,32
....4 ICSN74LVC125APW IC SN74LVC125APW 3 U14,15,16
....4 LD6703ARQHGRBYW Liquid-emitting Diode Red/Gree 13 LED32,33,34,35,37,38,39,40,41,42,43,44,45
....4 LDC191TBKT-5A Liquid-emitting Diode Blue SMD 3 D51,55,58
....4 LDKPT-1608SECK Liquid-emitting Diode amber SMD 11 D34,35,37,38,39,40,41,42,62,63,64
....4 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 13 D2,10,18,26,57,68,69,70,71,72,73,74,75
....4 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 8 D3,4,11,12,19,20,27,28
....4 LDKPT-1608ZGC Liquid-emitting Diode Green SMD 20
D5,6,7,8,9,13,14,15,16,17,21,22,23,24,25,2
9,30,31,32,33
....4 LDL-S291SWC-ML5 LED White SMD 0603 120° 11 D1,36,52,53,54,56,60,61,65,66,67
....4 RS000010J03 RESISTOR 0 5% SMD 0603 11
R25,26,154,200,201,202,203,204,205,206,2
07
....4 RS002K10F03 RESISTOR 2K 1% SMD 0603 20
R31,32,33,34,35,39,40,41,42,43,47,48,49,5
0,51,55,56,57,58,122
....4 RS010010F03 RESISTOR 100 1% SMD 0603 24
R29,30,37,38,45,46,53,54,59,62,64,66,68,7
0,73,76,78,80,135,139,142,171,172,193
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 26
R60,61,63,65,67,69,71,72,74,75,77,79,81,8
2,83,84,85,86,87,155,156,159,173,174,175,
176
....4 RS015010F03 RESISTOR 150 1% SMD 0603 57
R27,90,91,93,94,96,97,99,100,108,109,111,
112,114,115,117,118,123,124,125,126,127,
128,129,130,131,136,137,138,140,141,145,
146,147,148,149,150,151,152,160,161,162,
163,164,165,166,167,178,179,181,182,184,
185,187,188,190,191
....4 RS020010F03 RESISTOR 200 1% SMD 0603 4 R28,36,44,52
....4 RS030110F03 RESISTOR 301 1% 1/10W 0603 13
R89,92,95,98,107,110,113,116,177,180,183
,186,189
....4 RS051110F03 RESISTOR 511 1% SMD 0603 1 R169
....4 RS1K2410F03 RESISTOR 1.24K 1% SMD 0603 1 R158
....4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 23
R16,17,18,19,20,21,22,23,24,88,104,105,10
6,119,120,121,132,133,134,143,144,153,19
2
....4 RS4K7510F03 RESISTOR 4.75K 1% SMD 0603 1 R168
....4 TE6A2000601 Pin Header 90° Pitch 2.0mm 1 (J8)
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm 5 (J6,11,21,22,24)
....4 UHBLM18BD121SN1 IND BEAD 120 100MHz 200mA 0.40 SMT 5 L3,4,5,6,7
...3 TWPC19C018B01T Toggle SW PCB SMT/AI Assembly 1
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm Single Row 2 (J19,20)
...3 TWPC19C018D01T Toggle Switch PCB SMT/AI Assem 1
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm Single Row 1 (J23)
