Rane ONE - Page 22

...3 TWPC19C018E01T Start/Stop PCB SMT/AI Assembly 1
....4 AL2-54-0138 Moset BSS138 N-CH 3 Q100,101,102
....4 LD6703ARQHGRBYW Liquid-emitting Diode Red/Green/Blue SMD 2 LED36,46
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 3 R197,198,199
....4 RS015010F03 RESISTOR 150 1% SMD 0603 4 R102,103,195,196
....4 RS030110F03 RESISTOR 301 1% 1/10W 0603 2 R101,194
....4 TE6A2000602 Pin Header 180° Pitch 2.0mm Single Row 1 (J12)
..2 TWPC19C018A01 LEFT PCB Assembly(DIP) 1 40
...3 MT070446701 IRON PLATE 2 (ENC1,2)
...3 SWEN11-HSB1AF15 Switch Rotational Encode 20Pulse Push 2 ENC1,2
...3 SWEVQ11Y05B Switch Tact Stem Heigh:5mm 23
SW1,2,3,4,5,6,7,8,9,24,25,26,27,28,29,30,3
1,32,34,35,36,37,38
...3 VRR10301558 Potentiometer Rotary Volume:10K2B 6 R5,6,7,12,13,157
...3 VRR10301559 Potentiometer Rotary Volume:10K2B 8 R1,2,3,4,8,9,10,11
...3 VRS10304525 Potentiometer Slide 10K2B Travel 45mm 2 R14,15
...3 VRS10310022 Potentiometer Slide 10KB 100mm 15mm 1 R170
..2 TWPC19C018B01 Toggle SW PCB DIP Assembly 1 44
...3 BALED4X3.5A LED Holder (4*3.5) 4 (D43,44,45,46)
...3 HST050010BUL Heat Shink Tube f5*L10 4 (D43,44,45,46)
...3 LDLL304ZD2Y003 Liquid-emitting Diode Yellow 4 D43,44,45,46
...3 RU1204401 Rubber(Fixed Plate) 2 (MT1)
....4 MT1204422 Fixed Plate 2 -
...3 SWLBCR23M-095 Switch Toggle Dual Row 3 Pulse 2 S3,4
..2 TWPC19C018D01 Toggle Switch PCB DIP Assembly 1 45
...3 SWLBC23M-10K Switch Toggle Dual Row 2 S1,2
..2 TWPC19C018E01 Start/Stop PCB DIP Assembly 1 91
...3 SWDF-03S-6P-M-Z Micro switches SWDF-03S-6P-M-Z 1 SW10
0.1 MD998BYAH01 DD Motor 2 30
0.1 BW653245SS Washer 3M/M 1 36
0.1 ERE710 10mm E Ring 1 4
0.1 LAP22YAH456 Bar Code Label 1
0.1 MAG3510017 MAGNET 1 2
0.1 MT3205512 Motor Spindle 1 5
0.1 MT3210054 MAGNET BASE 1 1
..2 MT321003101 BEARING BASE 1
0.1 MT3210060 CENTER AXIS 1 3
0.1 MT3210061 SHELF 1 28
0.1 MT3210062 BRACKET 1 33
0.1 MT3210089 Metal Plate 1 14
0.1 MT3500102 RIVET 7 13
0.1 PT3210014 Dust Cover 1 30
0.1 PT351001402 IRON 1 7
0.1 PT3510015 COIL 1 9
0.1 RN3100111 C RING (10MM) 1 11
0.1 RN4050001 CS RING 1 12
0.1 SC0303SIBI Stop screw M3X3 2 17
0.1 SC0306RBNI Screw M3X6 PRN Tapping 1 35
0.1 SC0306WBNI Screw M3X6X8 PRWN W/WASHERTa 5 29
0.1 SC0330PBCI Screw M3X30 PPC Tapping 6 6
0.1 SC2606RINI SCREW M2.6X6 PPN 6 16
0.1 TWMT321000601 Stator Insulating Line Ring 1 8
0.1 TWMT321005601 Motor Base Assembly 1
..2 MT3210055 BRONZE SLEEVE 1 34
..2 MT3210056 IRON BASE 1 18
0.1 TWMT321005701 Douser Process 1
..2 MT3210057 DOUSER FIXED BASE 1 19
..2 MT3210068 DOUSER HOLDER 2 20
..2 NP632YAH104 DOUSER(900RPM) 1 21
