..2 RN042001 CS RING 1 23
0.1 TWMT321005801 Douser Process 1
..2 MT3210058 FIXED BASE 1 27
..2 MT3210069 DOUSER HOLDER 2 25
..2 NP632YAH105 DOUSER(900RPM) 1 26
..2 RN042501 FIXED RING (25MM) 1 24
0.1 WS109506205M Washer 2 22
0.1 WS663309IC Spring Washer 3# 2 31
0.1 TWPC18P00303 Motor PCB Assembly 1
..2 TWPC18P00303T MOTOR PCB SMD Assembly 1
-
...3 PC18P003 Motor PCB 1
-
...3 TWPC18P003A03T MOTOR PCB SMD Assembly 1
-
....4 AL2-51-0140 Schottky Barrier Rectiiers Di 1 D2
....4 CS104K1206X7R CCAP SMD 0.1uF/100V 10% 1206 X7R 1 C25
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 15 C1,2,3,4,5,6,7,12,16,21,22,23,27,30,31
....4 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 2 C19,40
....4 CS150J5003NPO CCAP SMD 15pF/50V 5% 0603 NPO 2 C38,39
....4 CS225K5006X7R CCAP SMD 2.2uF/50V 10% 1206 X7R 8 C13,14,17,18,20,24,26,32
....4 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 2 C28,34
....4 CS332K5003X7R CCAP SMD 3.3nF/50V 10% 0603 X7R 1 C10
....4 CS820J5003NPO CCAP SMD 82pF/50V 5% 0603 NPO 1 C11
....4 DIP6SMB47CA Diode TVS(47V) 1 ZD1
....4 DIS3J Diode S3J SMC 1 D1
....4 ECS10716D
Capacitor Electrolytic 100uF/16V D type SMD
3 EC1,2,3
....4 ECS22735GLE
ECAP LOW ESR 220UF/35V 10x10.3mm SMD
2 EC4,5
....4 HSDRV5013 DRV5013 Digital-Latch Hall E 3 H1,2,3
....4 IC74AHC245PW IC SN74AHC245PWR Octal Bus Tra 1 IC2
....4 ICDRV8313PWPR IC DRV8313PWPR Triple hal-H-B 1 IC4
....4 ICOPA2365AIDR IC OPA2365A Ampliier 1 IC5
....4 ICTLV1117LV33 IC TLV1117LV33DCYR 3.3V 1A Reg 1 IC1
....4 ICTPS54140DGQ IC TPS54140 1.5A 42V DCTODC Co 1 U1
....4 ICYH109P01 IC TMS320F28034+Program 1 IC3
.....5 ICTMS320F28034 IC TMS320F28034 Blank TQFP 1 -
....4 RS000010J03 RESISTOR 0 5% SMD 0603 1 R17
....4 RS004710F03 RESISTOR 47 1% SMD 0603 25
R4,7,9,13,14,15,16,18,28,29,30,31,32,33,34
,35,36,37,38,48,50,51,52,53,54
....4 RS010010F03 RESISTOR 100 1% SMD 0603 5 R42,43,44,47,62
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 13 R8,26,27,39,40,41,49,55,56,57,58,60,67
....4 RS01K210F03 RESISTOR 1.2K 1% SMD 0603 4 R45,46,61,66
....4 RS020K10F03 RESISTOR 20K 1% SMD 0603 2 R59,68
....4 RS02K210F03 RESISTOR 2.2K 1% SMD 0603 1 R25
....4 RS033K10F03 RESISTOR 33K 1% SMD 0603 4 R11,12,23,24
....4 RS047010F03 RESISTOR 470 1% SMD 0603 1 R80
....4 RS082010F03 RESISTOR 820 1% SMD 0603 2 R19,22
....4 RS0R0104F06 RESISTOR 0.01 1% SMD 1206 3 R63,64,65
....4 RS220K10F03 RESISTOR 220K 1% SMD 0603 1 R6
....4 RS53K610F03 RESISTOR 53.6K 1% SMD 0603 1 R2
....4 RS698K10F03 RESISTOR 698K 1% SMD 0603 1 R5
....4 UH201209T-600Y BEAD 60±25% 3A 0805 4 L5,8,9,10
....4 UH453232T-3R3K Capacitor 3.3UH 4 L2,4,6,7
....4 UH465516-351 Common mode inductance-350 1 L3
....4 UHBLM15AG102SN1 Inductor Bead 1000 200mA 040 4 L11~14
....4 UHDRRI125-101M Inductor, 100UH±20% 1.3A SMD 1 L1
....4 XTM10000XB Crystal 10MHz 3225+SMD Fundame 1 X1
...3 TWPC18P003B01T Optical Encoder PCB SMD Assemb 1
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 1 C9
...3 TWPC18P003C01T Optical Encoder PCB SMD Assemb 1
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 1 C15
..2 TWPC18P003A02 Motor PCB Assembly 1
...3 FCN2S1001601 FCN Dual Touch 180° 1 FCN1
